Endress Hauser Analog conductivity sensor Indumax CLS50

Name: Endress Hauser Analog conductivity sensor Indumax CLS50
Brand: Endress+Hauser
Price: 1 USD

Quality Endress Hauser Analog conductivity sensor Indumax CLS50 for sale

Brand Name : Endress+Hauser

Model Number : CLS50-16D6/0 CLS50-A1B6

Certification : CE

Place of Origin : Germany

MOQ : 1pc

Price : negotiable

Payment Terms : T/T

Supply Ability : 100pcs per month

Delivery Time : 12-14weeks

Packaging Details : standard carton packing

Approval : Non-hazardous area + UKCA marking

Process Connection : Thread G 3/4

Sensor-; Seal-;Adapter : PEEK; Viton; PEEK

Cable Connection : 10m fixed cable, max. 180oC

Gross weight : 1.616 Kilogram

Country of origin : DE

Contact Now

Endress Hauser Analog conductivity sensor Indumax CLS50

Indumax CLS50 is an inductive conductivity sensor for standard, hazardous and high-temperature applications. Benefit from high chemical resistance and long durability thanks to robust materials (PFA, PEEK). Moreover, it is insensitive to soiling and performs reliable and repeatable even in harsh and aggressive media. The wide temperature range of -20 to +180 °C leaves nothing to be desired.

Indumax CLS50 measures toroidal conductivity in:

Chemicals:
- Concentration measurement of acids and bases
- Quality monitoring of chemical products in tanks and pipes
Food & beverages:
- Phase separation of product/product mixtures in pipe systems
Wastewater industry:
- Inlet monitoring

With its international explosion protection approvals, such as ATEX, FM, CSA, NEPSI, it is suitable for hazardous areas.

Measuring principle	Inductive
Characteristic	Inductive conductivity cell made of highly resistant material for conductivity and concentration neasurements in process applications.
Measurement range	2µS/cm - 2000 mS/cm
Measuring principle	Inductive conductivity measurement
Design	- No direct contact with the media because of the sensor coating made of highly resistant material.
Material	PEEK or PFA
Dimension	Electrode: outside diameter: appr. 47 mm inside diameter: appr. 15 mm
Process temperature	max. 180°C (PEEK) (356°F)max. 125°C (PFA) (254°F)
Process pressure	max. 20 bar (PEEK) (290 psi) max. 16 bar (PFA) (233 psi)
Temperature sensor	Integrated Pt100
Ex certification	ATEX
Connection	Process connection: NPT1", DN50, AINSI, JIScable: fixed cable connection.
Ingress protection	IP67
Additional certifications	Calibration certification of the cell constant.

Endress Hauser Analog conductivity sensor Indumax CLS50

Product Tags:

CLS50 Analog conductivity sensor

Endress Hauser Analog conductivity sensor

Endress Hauser Analog conductivity sensor Indumax CLS50 Images
